Semiconductor and Integrated Circuit Devices TI.com RasClock - Raspberry Pi Real Time Clock Module V3.0 RasClock is a highly accurate real-time clock that plugs directly into the Raspberry Pi and includes a battery backup. The module is installed directly into the GPIO header pins with no wiring or soldering. It uses the 3.3V, GND SDA and SCL pins. The module stays within the outline of the Raspberry Pi and sits lower than video output so can be easilly installed within most cases. Updated V3.0 - The Rasclock now features an 8 Pin Header input, so boards can be stacked on top! RasClock utilises the highly accurate NXP PCF2127AT chip and features: Very accurate timekeeping (typically ±3ppm or <2 minutes deviation per year). Why do I need a Real Time Clock for my Raspberry Pi? The Raspberry Pi is an ultra-small and ultra-low cost computer. The Raspberry Pi will simply revert back to the standard date and time settings (usually 30 November 1999) when the network connection is removed. How do I set it up? Set up is easy, simply follow the guide Outlined in the ModMyPi Raspberry Pi Tutorial Here!
AVRISP mkII AVR XMEGA A Series 8/16-bit AVR XMEGA A1U Microcontroller, 64KB Flash, 100-pin, USB Full-speed Device 8/16-bit AVR XMEGA A1U Microcontroller, 128KB Flash, 100-pin, USB Full-speed Device 8/16-bit AVR XMEGA A3U Microcontroller, 64KB Flash, 64-pin, USB Full-speed Device 8/16-bit AVR XMEGA A3U Microcontroller, 128KB Flash, 64-pin, USB Full-speed Device 8/16-bit AVR XMEGA A3U Microcontroller, 192KB Flash, 64-pin, USB Full-speed Device 8/16-bit AVR XMEGA A3U Microcontroller, 256KB Flash, 64-pin, USB Full-speed Device 8/16-bit AVR XMEGA A3BU Microcontroller, 256KB Flash, 64-pin, USB Full-speed Device 8/16-bit AVR XMEGA A4U Microcontroller, 16KB Flash, 44-pin, USB Full-speed Device 8/16-bit AVR XMEGA A4U Microcontroller, 32KB Flash, 44-pin, USB Full-speed Device 8/16-bit AVR XMEGA A4 Microcontroller, 64KB Flash, 44-pin, USB Full-speed Device 8/16-bit AVR XMEGA A4 Microcontroller, 128KB Flash, 44-pin, USB Full-speed Device 8/16-bit AVR XMEGA A1 Microcontroller, 64KB Flash, 100-pin AVR XMEGA B Series megaAVR
Corporation - Microcontrollers, 32-bit, and touch solutions Saleae Logic Goodbye frustration, hello fun. And for just $149, it's kind of a no brainer. Voltage range Logic accepts voltages from -.5V to 5.25V, and has standard CMOS thresholds of .8V for logic low, 2.0V for logic high. Comes complete Start debugging within 5 minutes of opening your new Logic; everything is included: An ultra-flexible 22AWG 64/40 wire harness, 9 high-quality micro-hook probes, a USB cable (2 meter mini-B to A), and a nice carrying case. Worry free Logic comes with a 2-year warranty. Top-notch support Email or call us anytime. Overview Logic is a logic analyzer used to record, view, and measure digital signals. Supported Protocols The Saleae software supports the following protocols: asynchronous serial, I2C, SPI, CAN, 1-Wire, UNI/O, I2S/PCM, MP Mode 9-bit Serial (i.e. Enclosure We love well made tools. Protection Logic’s inputs are protected against overvoltage conditions via current-limiting resistors and ultra-low-capacitance diode clamps.
Making PCBs How to make really really good homemade PCBs Note - this article is original material. There is currently a plagiarised copy of it on the site of an Indian electronics magazine credited to a rip-off artist called Indrani Bose. This page is a guide to producing consistently high quality PCBs quickly and efficiently, particularly for professional prototyping of production boards. With the methods described, you can produce repeatably good single and double-sided PCBs for through-hole and surface mount designs with track densities of 40-50 tracks per inch and 0.5mm SMD pitches. This information has been condensed from over 20 years' experience of making PCBs, mostly as prototypes of boards to be put into production. I will only consider photographic methods in depth - other methods such as transfers, plotting on copper and the various 'iron-on' toner transfer systems are not really suited for fast, repeatable use. Artwork generation Media Output devices Photoresist PCB laminates Exposure Etching
Nest Teardown Awhile ago I read about Nest, a newfangled thermostat with a color display and some interesting ‘learning’ techniques for keeping your home warmed or cooled, as sensible as possible. Did I mention the beast has IR proximity, PIR movement, humidity, magneto scroll, and a mini USB connector? Oh. It’s kind of awesome, but it comes at a price. Hi Matt, This offer is a great idea! From your friends at SparkFun,-Nathan Much to my surprise and honor, I got a response from Matt: Thanks for the note Nathan! No way! Disclosure time: We didn’t get Nest for free. After tearing apart the Nest then re-assembling, it actually continued to function (a first for me!).
High Power LED Driver Circuits High-power LED's: the future of lighting! but... how do you use them? where do you get them? 1-watt and 3-watt Power LED's are now widely available in the $3 to $5 range, so i've been working on a bunch of projects lately that use them. in the process it was bugging me that the only options anyone talks about for driving the LED's are: (1) a resistor, or (2) a really expensive electronic gizmo. now that the LED's cost $3, it feels wrong to be paying $20 for the device to drive them! So I went back to my "Analog Circuits 101" book, and figured out a couple of simple circuits for driving power LED's that only cost $1 or $2. This instructable will give you a blow-by-blow of all the different types of circuits for powering Big LED's, everything from resistors to switching supplies, with some tips on all of them, and of course will give much detail on my new simple Power LED driver circuits and when/how to use them (and i've got 3 other instructables so far that use these circuits).
